BERTONE & FIAT X1/9 Parts

Service Parts for FIAT and BERTONE X1/9

Unless indicated otherwise all items shown on this web page are for BERTONE and FIAT branded X1/9 vehicles that were manufactured by Carrozzeria Bertone in Grugliasco, Italy for sale in USA from 1979 to 1989.


Bertone X1/9 Car Gallery

BERTONE X1/9


ENGINE

Belts

FIAT BERTONE X1/9 Water Pump Belt

Part Number Description Price Each
US $
7604704 Water Pump to Alternator 1500 $15.00
7618732 Crank to Water Pump 1500 $12.00
Water Pump - A/C - Alt. 1500 $12.00

Timing Belt

FIAT BERTONE X1/9 Timing Belt

Part Number Description Price Each
US $
4242396 FIAT OEM Timing Belt 1500 $30.00
4401261 PIRELLI Timing Belt 1500 $32.00

IGNITION

Distributor

Cap

Distributor Cap X1/9
Distributor Cap X1/9

Part Number Description Price Each
US $
BOSCH Cap Sold Out

Rotor

Distributor Rotor X1/9
Distributor Rotor X1/9

Part Number Description Price Each
US $
BOSCH Rotor Sold Out

Wires


Ignition Wire Set X1/9
Ignition Wire Set X1/9

Part Number Description Price Each
US $
Ignition Wires Set Sold Out

Ignition Module

Part Number Description Price Each
US $
FIAT OEM USED (tested) $60.00
FIAT OEM NEW $120.00

Spark Plugs


BOSCH Platinum Spark Plug
BOSCH Platinum Spark Plug

Part Number Description Price Each
US $
WR8DPX BOSCH Platinum $5.50
FIAT OEM NEW $3.20


FUEL INJECTION

Fuel Injectors


Fuel Injector
Fuel Injector

Part Number Description Size Q* Price Each
US $
EFI-B1 Fuel Injector BOSCH OEM 4 $36.00
0 280 150 123 Fuel Injector BOSCH OEM 4 $86.00
4320627-2 Fuel Injector FIAT OEM 4 $60.00

Q = Quantity used per vehicle

Fuel Pump

Fuel Filter EFI
Fuel Pump and has 12 millimeter barb on INLET and 8 millimeter barb on OUTLET.

Part Number Description Price Each
US $
FP00 Fuel Pump EFI - Generic $60.00
FP01 Fuel Pump EFI - BOSCH $160.00

Fuel Filter

Secondary Fuel Filter EFI
This fuel filter is used AFTER fuel pump and has 8 millimeter barb on both INLET and OUTLET.

Part Number Description Price Each
US $
FF02 Fuel Filter EFI $24.00


Primary Fuel Filter EFI
This filter is used BEFORE fuel pump and has 12 millimeter barb on both INLET and OUTLET.

Part Number Description Price Each
US $
FF01 Fuel Filter Primary EFI $20.00

Fuel Primer Module

Electronic Fuel Injection
Electric Fuel Pump Timer
6 seconds ON Duty

For more information follow the link below:
EFI-TIMER 6s


Relays

Intermittent Wiper Relay
BOSCH Dual EFI Relay

Part Number Description Price Each
US $
0 332 514 127 Dual Relay BOSCH $102.00

Sensors

Part Number Description Price Each
US $
4393601 Cooling System Temperature Sensor $40.00

Cooling System Temperature Sensor
BOSCH Cooling System Temperature Sensor for Fuel Injection


COOLING SYSTEM

Sensor Switch

Part Number Description Price Each
US $
4424393 Cooling System Radiator Fan Thermo Switch $12.00

Cooling System Radiator Fan Thermo Switch
Cooling System Radiator Fan Thermo Switch
Two-wire with bullet-style connector pigtail

ELECTRICAL

Switches

Central Console Switches
Bertone Switches
Central Console BS Switches and Instrument Lights Dimmer


Both the AS and BS type switches fit into the Central Console Switch Holder in 1979 to 1989 X1/9 cars.
BS type was installed as OEM part in most 1979 to 1988 FIAT and BERTONE X1/9 cars.
AS type was used as "optional" part and used in the 1989 and "Speciale" X1/9 cars. The AS switches were usually used in the second lower row, and are slightly recessed in comparison to the BS type switch.
Both types mate with the OEM wiring connectors.

Part Number Description Price Each
US $
E SW BS-90 Switch Aux Sold Out
E SW BS-69 Switch Hazard $32.00
E SW AS-10 Switch Interior Light $30.00
E SW BS-10 Switch Interior Light Sold Out
E SW AS-20 Switch Fog Light Rear $26.00
E SW AS-22 Switch Fog Light Front $30.00
E SW AS-50 Switch Rear Defrost $26.00
E SW BS-50 Switch Rear Defrost $30.00
E SW AS-30 Switch Dot Sold Out
E SW AS-40 Switch Circle Sold Out
E SW BS-00 Switch Blank Cover $6.00
E SW AS-70 Switch Power Antenna Sold Out
E RR BS-80 Controller Instrument Light Brightness Sold Out

Hazard Flasher Switch
Hazard Flasher Switch BS

Interior Lights Switch
Interior Lights Switch BS

Fog Lights (Rear) Switch
Fog Lights (Rear) Switch AS

Fog Lights (Front) Switch
Fog Lights (Front) Switch AS

Demist Heater (Rear) Switch
Demist Heater (Rear) Switch AS

Demist Heater (Rear) Switch
Demist Heater (Rear) Switch BS

Universal DOT Switch AS
Universal DOT Switch AS

Universal Circle Switch AS
Universal Circle Switch AS

Antenna Switch AS
Antenna Switch AS

Brake Lights Switch
Part Number Description Price Each
US $
E SW BP-01 Brake Lights Switch $20.00

Brake Lights Switch
Brake Lights Switch

Fuses

GBC Fuses

BOSCH Type fuses have been used in OKA, YUGO, FIAT and BERTONE vehicles.

BOSCH Fuses
Mechanical Specification of BOSCH Fuses
also known as torpedo, ATS, or GBC type fuses
Part Number Description Body Color Price Each
US $
EF GBC 5A Fuse 5A Yellow $0.26
EF GBC 8A Fuse 8A White $0.26
EF GBC 16A Fuse 16A Brown $0.26
EF GBC 25A Fuse 25A Blue $0.26
EF GBC 30A Fuse 30A Black $0.26
GBC Fuses
GBC Fuse also known as torpedo type fuse

GBC In-Line Fuse Holder
Part Number Description Body Color Price Each
US $
EF GBC H1 Fuse Holder Salmon $5.20

GBC Fuses
GBC In-Line Fuse Holder

ATC Fuses

ATC Automotive fuses have been used in OKA and BERTONE vehicles.

Part Number Description Body Color Price Each
US $
EF ATC 3A Fuse 3A Violet $0.40
EF ATC 5A Fuse 5A Tan $0.40
EF ATC 10A Fuse 10A Red $0.30
EF ATC 15A Fuse 15A Teal $0.36
EF ATC 20A Fuse 20A Yellow $0.36
EF ATC 25A Fuse 25A Clear $0.36
EF ATC 30A Fuse 30A Green $0.36
EF ATC 35A Fuse 35A Purple $0.42
EF ATC 40A Fuse 40A Orange $0.42
ATC Fuses
ATC Fuse also known as blade type fuse

Relays


Intermittent Wiper Relay
Intermittent Wiper Relay
4423970
1979-89 Fiat and Bertone X1/9s
Also fitted to 1983-85 Pininfarina 124 Spider

Intermittent Wiper Relay
BOSCH Dual EFI Relay

Chime Alert Relay
Chime Alert Relay


Part Number Description Use Q* Price Each
US $
4423970 Intermittent Relay Wiper 1 $32.00
4320629 SPST 12V 30A Relay OEM 4 $10.00
4320627 SPDT 12V 30A Relay OEM 4 $12.00
0 332 514 127 Dual Relay BOSCH EFI 1 $102.00
ERF 4 Emergency Flasher Relay Hazard 1 $22.00
4454755 Chime Alert Relay Door 1 $28.00
5936319 Time Delay (10 seconds) Relay Courtesy Lights 1 $55.00
RE42 SPDT 12V 30A Relay Starter ** 1 $9.00

Q = Quantity used per vehicle

For other Relays see Web Page: Automotive Relays


** For Starter Relay Upgrade see Web Page: StarterRelayRE42.html


Bulbs

Bulb #67 - Tail Light Bulb #1157 - Front Turn and Park Bulb #1156 - Stop Light

Part Number Description Use SAE Q* Price Each
US $
EB 67 4cp (8W) Tail Lights T 2 $1.00
EB 1157 32/3cp (27/8W) Front Turn and Park IP 2 $1.50
EB 1156 32cp (27W) Stop Lights
Rear Turn Indicator
Reverse Lights
S
I
R
6 $1.25
EB SM 265mA (194) Side Markers (F/R) P2 4 $1.35
EB I3 40mA Instrument Cluster
Signal Lamps
11 $1.12
EB I5 220mA (158) Instrument Cluster
Illumination
4 $1.24
EB IL   Interior Lights 2 $1.86
EB 9003 H4 (55W/45W) 7" Headlight (Hi/Lo) 2 $25.00

Q = Quantity used per vehicle


Sockets

Part Number Description Size Q* Price Each
US $
ES CL Cigarette Lighter Socket, Lighted OEM 1 $15.00
ES 12V 12V Power Socket MRX 2 $10.00

AUDIO

Speakers

Part Number Description Size Q* Price Each
US $
EASP 46 Oval Speaker Rear 4 x 6 " 2 $15.00

Q = Quantity used per vehicle


Infinity Speaker
Infinity 4x6 Inch 20 Watt Speaker

Antenna

Part Number Description Q* Price Each
US $
EAAA Automatic Antenna Kit 1 $65.00

Antenna Kit
Automatic Antenna Kit

INSTRUMENTS

Clock

Part Number Description Q* Price Each
US $
EDC-12 Digital Clock 1 $55.00

Antenna Kit
Digital Clock Veglia
Red LED, two button control

This Digital Clock is OEM fit for FIAT and BERTONE X1/9 as well as may other FIAT, MASERATI, LANCIA and INNOCENTI vehicles.
This is a Factory OE Black 12 Hour Digital Clock by Veglia applicable also to some FIAT 124 Spider, the FIAT Strada, and some LANCIA Beta models.

CAUTION:
Not all vehicles are wired identically, also the harness colors may differ from the color code on the clock itself, therefore make sure that the clock is wired as per table below:

Wire Color Function Connect to Voltage
Black Ground Ground -12VDC
Red Power Battery + +12VDC
Yellow Display ON Ignition + +12VDC
Gray Display Dim Marker Lights + +12VDC

Instrument Cluster


BODY

Doors

Targa Top

Front Hood

Engine Cover

Rear Trunk

Front Bumper

Rear Bumper

Suspension

Front Struts

Rear Struts

BRAKES

Rotors

Disk Brake Rotor
Disk Brake Rotor

Part Number Description Q* Price Each
US $
BR U Disk Brake Rotor (Front/Rear) 4 $26.00

Q = Quantity used per vehicle

NOTE:
Right and Left as well as Front and Rear Rotors are the same

Brake Pads

Braker Pad Front Braker Pad Rear

Part Number Description Q* Price Each
US $
D54 Disk Brake Pad (Front) - each 4 $6.00
D71 Disk Brake Pad (Rear) - each 4 $6.00

Q = Quantity used per vehicle

NOTE:
Right and Left as well as Outer and Inner Pads are the same

Brake Lines

Brake Hose Front Brake Hose Rear

Part Number Description Q* Price Each
US $
BH F Brake Hose (Front) [R/L] - each 2 $26.00
BH R Brake Hose (Rear) [R/L] - each 2 $26.00

Q = Quantity used per vehicle

NOTE:
Right and Left Hoses are the same


Brake Calipers

Brake Caliper Front Brake Caliper Rear

Part Number Description Q* Price Each
US $
BC FR Brake Caliper (Front) [Right] 1 $116.00
BC FL Brake Caliper (Front) [Left] 1 $116.00
BC RR Brake Caliper (Rear) [Right] 1 $146.00
BC RL Brake Caliper (Rear) [Left] 1 $146.00

Q = Quantity used per vehicle


Master Cylinder

Brake Master Cylinder
Brake Master Cylinder

Part Number Description Q* Price Each
US $
BR MC Brake Master Cylinder 1 $72.00

Q = Quantity used per vehicle

  • Fiat Bertone X1/9 All (1973-88)

Brake Fluid

We recommend SynLube™ Stop-4-Life™ Extra Long-Life DOT 5.1 Brake Fluid

Part Number Description Size Price Each
US $
0-91275-51105 Extra Long-Life DOT 5.1 1/2 Liter $19.00
0-91275-51110 Extra Long-Life DOT 5.1 1 Liter $36.00
0-91275-51148 Extra Long-Life DOT 5.1 48 US Fluid Ounces $55.00

For more information follow the link below to SynLube.com website:
http://www.synlube.com/brake-fluid.html#DOT51LL

WHEELS

OEM X1/9 Wheel Specifications:

  • 4x98 mm bolt pattern
  • 52 mm hub-centric center
  • 102 mm of backspacing
  • 13" x 5" in width

Cromodora

Cromodora 13x5 Wheel

Part Number Description Size Q* Price Each
US $
CD-179 Alloy Wheel "Tron" (used) 13 x 5 " 4 $95.00
CD-179-CC Plastic Center Cover 4 Sold Out

Q = Quantity used per vehicle


OEM X1/9 Wheel Bolt Specifications:

  • M12x1.25 mm bolt thread
  • Seat Style: Conical Seat - 60 Deg
  • Bolt Grade: Grade 5
  • Hex Size: 19 mm
  • Thread Length: 19 mm
  • Overall Length: 52 mm

Wheel Bolt

Part Number Description Size Q* Price Each
US $
WB-145 Wheel Bolt M12x1.25 HEX19 16 $3.00
WB-BB Wheel Bolt (BERTONE) M12x1.25 HEX19 16 $5.00

Q = Quantity used per vehicle


TIRES

Part Number Description Size Q* Price Each
US $
RT-13-1 Radial P Tire 165/70 R13 5 Sold Out

Q = Quantity used per vehicle


Manuals and Literature

Sales

Sales Brochure 8.5"x11" Full Color (Bertone X1/9 1985-86 North America) - NEW

BERTONE 1986 Sales Brochure

This is an 8-page sales / promotional brochure for Bertone X1/9, North America, covering 1985 and 86 model years.

Full color gloss pages, featuring photos of the factory, assembly lines, and vehicles.

Descriptions of Bertone's storied history and a comprehensive review of the X1/9's technical underpinnings and color combinations for 1985 and 86 model years.

A must-have for any Fiat / Bertone X1/9 enthusiast or memorabilia collector.

Part Number Description Size Q* Price Each
US $
SB-1985 Sales Brochure 8 Pages $12.75

Sales Tri Fold 8.5"x11" Full Color (Bertone X1/9 1985-86 North America) - NEW

BERTONE 1986 Sales Tri Fold

This is sales / promotional tri fold for Bertone X1/9, North America, covering 1985 and 86 model years.

Full color gloss page, featuring photos of the factory, assembly lines, and vehicles.

Descriptions of Bertone's storied history and a comprehensive review of the X1/9's technical underpinnings and color combinations for 1985 and 86 model years.

Part Number Description Size Q* Price Each
US $
STF-1985 Sales Tri Fold 1 Page $5.00


OKA AUTO USA • P.O. Box 19294 • Jean, Nevada 89019 • USA
e-mail: okaauto@aol.com   •  Phone:   702-683-8292
